| BU2002RWLG | BU3002RWLG | BU5002RWLG |
|---|
Operation method | Full-time inverter supply method (high efficiency) |
AC input | Rated input voltage | 200/208/220/230/240 VAC |
Startup voltage range | 200 V mode: 160±2 to 288±2 VAC, 208 V mode: 167±2 to 278±2 VAC 220 V mode: 176±2 to 278±2 VAC, 230 V mode: 184±2 to 278±2 VAC 240 V mode: 192±2 to 278±2 VAC, 100 V mode: 160±2 to 288±2 VAC |
Input voltage range | 200 V mode: 170±2 to 278±2 VAC, 208 V mode: 177±2 to 278±2 VAC 220 V mode: 186±2 to 278±2 VAC, 230 V mode: 194±2 to 278±2 VAC 240 V mode: 202±2 to 278±2 VAC, 100 V mode: 170±2 to 278±2 VAC |
Input frequency | 50/60 Hz±1, 3, 5, or 14% (5% in the factory settings) |
Maximum current (at rated voltage) | 9 A | 14 A | 23 A |
Phase | Single-phase, two-wire (grounded) |
Input plug | Terminal block | NEMA L6-30P / Terminal block |
AC output | Output capacity (upper limit) | 2000 VA/1400 W (1000 VA/700 W in 100 V mode) | 3000 VA/2100 W (1500 VA/1050 W in 100 V mode) | 5000 VA/3500 W (2500 VA/1750 W in 100 V mode) |
Rated current (at rated voltage) | 10 A | 15 A | 25 A |
Switching time | Uninterrupted |
Output voltage (commercial operation) | 200 V mode: 200 VAC±2%, 208 V mode: 208 VAC±2% 220 V mode: 220 VAC±2%, 230 V mode: 230 VAC±2% 240 V mode: 240 VAC±2%, 100 V mode: 100 VAC±5% |
Output voltage (backup operation) | 200 V mode: 200 VAC±2%, 208 V mode: 208 VAC±2% 220 V mode: 220 VAC±2%, 230 V mode: 230 VAC±2% 240 V mode: 240 VAC±2%, 100 V mode: 100 VAC±5% |
Output frequency (commercial operation) | Synchronized with input frequency |
Output frequency (backup operation) | 50/60±0.5 Hz |
Output waveform (in commercial power mode/battery mode) | Sine wave/Sine wave |
Phase | Single-phase, two-wire |
Output receptacles | Terminal block | NEMA L6-30R × 2, terminal block |
Battery | Sealed lead battery life expectancy | 5 years (ultralong operating life) (ambient temperature 25°C) |
Battery capacity (V/Ah) (× Quantity) | 12 VDC/9 Ah (× 4) | 12 VDC/9 Ah (× 6) | 12 VDC/9 Ah (× 12) |
Charging time | 8 hours |
Backup time (25°C, initial characteristics) | 5 min (1400 W) | 5 min (2100 W) | 5 min (3500 W) |
Dimensions in mm (W × D × H) | 430×660×88 (2U) | 430×700×132 (3U) |
Weight of unit | Approx. 28 kg | Approx. 33 kg | Approx. 61 kg |
Operating environment temperature/humidity | 0 to 40°C/25% to 85% with no condensation |
Storage environment temperature/humidity | -15 to 50°C/10% to 90% (with battery fully charged, stored with no condensation) |
Noise regulation | VCCI Class A compliant |
Safety standard compliance | UL1778/CE/RoHS compliance |
Internal power consumption (normal /maximum) | 70 W/145 W | 148 W/265 W | 249 W/480 W |
Cooling method | Forced air cooling |
Serial communication (RS-232C) (interface) | ⬛ (D-sub 9pin) |
Contact signal (interface) | ⬛ (D-sub 9pin) |
